| Camera type | Mirrorless full-frame system camera |
|---|
| Buffer memory | 4 GB DNG™: > 999 recordings JPG: > 999 recordings |
|---|
| Storage medium | UHS-II (recommended), UHS-I, SD/SDHC/SDXC memory card |
|---|
| Material | Full-metal housing made of aluminum and magnesium, leatherette, cover, splash-water protected in compliance with IEC standard 60529 (protection type IP54) |
|---|
| Lens mount | Leica L bayonet with contact strip for communication between lens and camera |
|---|
| Operating conditions | -10 to +40°C |
|---|
| Interfaces | ISO accessory shoe with additional control contacts, HDMI jack 2.0b Type A, USB 3.1 Gen1 Type C, Audio-Out 3.5 mm/Audio-In 3.5 mm, communication interface in the base cover for multifunction hand grip |
|---|
| Tripod thread | A 1⁄4 DIN 4503 (1⁄4”) with stainless steel in the base |
|---|
| Dimensions (WxHxD) | 146 x 107 x 83 mm |
|---|
| Weight | approx. 840 g (without battery), approx. 920 g (with battery) |
|---|
| Sensor size | CMOS sensor, pixel pitch: 5.94 μm / Fullframe (24.6 MP): 6072 x 4056 pixels / APS-C (10.6 MP): 3984 x 2656 pixels |
|---|
| Image Stabilization | 5 axis Body Image Stabilization. Camera stabilizes up to 5.5 stops |
|---|
| Filter | RGB color fi lter, UV/IR filter, no low-pass filter |
|---|
| Processor | Leica Maestro series (Maestro III) |
|---|
| File formats | Photo: DNG™ (raw data), DNG + JPG, JPG (DCF, Exif 2.31) Video: MP4: H.264/MPEG-4 AVC (Audio Format: 2ch 48 kHz/16 bit, AAC), MOV: H.264/MPEG-4 AVC (Audio Format: 2ch 48 kHz/16 bit, LPCM) |
|---|
| Picture resolution | DNG™: 6000 x 4000 pixels (24 MP), JPG: 6000 x 4000 pixels (24 MP), 4272 x 2848 pixels (12.2 MP), 2976 x 1984 pixels (5.9 MP)APS-C: DNG: 3963 x 2624 pixels (10.3 MP), JPG: 3963 x 2624 pixels (10.3MP), 2736 x 1824 pixels (5 MP), 1920 x 1280 pixels (2.5MP) |
|---|
| Color depth | DNG™: 14 bit, 12 Bit (super high continous shooting), JPG: 8 bit |
|---|
| Color space | Picture: sRGB, Video: Rec. 709/Rec. 2020 (HLG/L-Log) |
|---|
| File size | DNG™: approx. 44 MB, JPG: depending on resolution and image content.
Video: unlimited, max. fi le size: 96 GB |
|---|
| Recording Mode Video | Video mode: P - A - S – M / Cine mode: M |
|---|
| Video resolution | 35 mm - C4K (17:9) 4096x2160 pixels (Sensor range: 6000 x 3168 pixels)35 mm - 4K (16:9) 3840x2160 pixels (Sensor range: 6000 x 3368 pixels)35 mm - Full HD (16:9) 1920x1080 pixels (Sensor range: 6000 x 3368 pixels)APS-C - C4K (17:9) 4096x2160 pixels (Sensor range: 4128 x 2176 pixels)APS-C - 4K (16:9) 3840x2160 pixels (Sensor range: 3984 x 2240 pixels)APS-C - Full HD 1920x1080 pixels (Sensor range: 3984 x 2240 pixels) |
|---|
| Bit Rate | 8/10 bit for recordings on SD card, 10 bit via HDMI output |
|---|
| Video Gamma | Rec. 709, L-Log Rec. 2020, HLG Rec. 2020 |
|---|
| Viewfinder (EVF) | Resolution: 5,760,000 dots, 120 fps, magnification: 0.78x, aspect ratio: 4:3, frame coverage: 100%, exit pupil position: 21 mm, setting range +2/-4 diopters, with eye sensor for automatic switchover between viewfinder and LCD panel, time delay 0.005 s |
|---|
| LCD panel | 3.2“ (backlight LED) with anti-fingerprint and anti-scratch coating, 2,100,000 pixels (dots), format 3:2, touch control available |
|---|
| Top display | 1.28“ highly reflective trans-reflective monochrome LCD, 128 x 128 pixels, viewing angle 120°; anti-fingerprint coating |
|---|
| Shutter type | Electronically controlled focal plane shutter/electronic shutter |
|---|
| Shutter speeds | Mech. shutter: bulb, 30 min to 1⁄8000 s / Electr. shutter function: 60 s to 1⁄16000 s / Flash Synch: up to 1/250 s |
|---|
| Shutter button | Two-stage (1st stage: Activation of the camera electronics including autofocus and exposure |
|---|
| Self-timer | Delay time: 2 s or 12 s |
|---|
| Picture Series | Single, Continuous Low Speed (2 fps), Continuous Medium Speed (5 fps), Continuous High Speed (9 fps without AFc/AE/WB), Continuous Super Speed (25 fps with electr. shutter function without AFc/AE/WB), Interval Shooting, Exposure Bracketing, Multishot |
|---|
| Multishot | Generates 2 DNGs: 1x 24 MP, 1x 96 MP (8 pictures are combined into one high-res image) |
|---|
| Focus Mode | Automatic (Autofocus in modes iAF/AFs/AFc/Touch AF) or manual. With manual setting: Auto Magnification and Focus Peaking optionally available as focus aids |
|---|
| Autofocus system | Based on contrast metering and depth mapping |
|---|
| Autofocus modes | Smart AF (autonomously selects AFs and AFc), AFs (picture taken only after successful focusing), AFc (picture can be taken at any time), AF setting can be saved |
|---|
| Autofocus Metering Methods | Spot (can be shifted), Field (can be shifted), Multi-Field, Zone (can be shifted), Face detection, object Tracking, optional Touch AF |
|---|
| Autofocus Metering Fields | 225 |
|---|
| Exposure metering | TTL (‚Through The Lens‘ exposure metering) |
|---|
| Exposure Metering Methods | Spot, Center-Weighted, Multi-Field |
|---|
| Exposure modes | Automatic program (P), Aperture priority (A): manual aperture setting, Shutter priority mode (S): manual shutter speed setting Manual (M): manual setting for shutter speed and aperture |
|---|
| Exposure Compensation | ±3 EV in 1⁄3 EV increments or 1/2 EV increments |
|---|
| Automatic bracketing | 3 or 5 exposures, up to ±3 EV, in 1⁄3 EV increments Shift function: up to ±3 EV |
|---|
| ISO sensitivity range | Auto ISO: ISO 100 to ISO 100000 Manual: ISO 50 to ISO 100000 |
|---|
| Flash unit connector | About the accessory shoe |
|---|
| Flash sync time | Flash: 1⁄250 s, slower shutter speeds available, automatic changeover to TTL linear flash mode with HSS-compatible Leica flash units if sync time is undercut |
|---|
| Flash exposure metering | Using center-weighted TTL pre-flash metering with Leica flash units (SF 26, 40, 58, 60, 64) or with system-compatible flash units, flash remote control SF C1 |
|---|
| Flash exposure compensation | SF 40: ±2 EV in 1⁄2 EV incrementsSF 60: ±2 EV in 1⁄3 EV increments |
|---|
| Microphone | Stereo internal + microphone input 3.5 mm stereo jack + power supply voltage (approx. 2.5 V) |
|---|
| Speaker | Mono internal + headphones output 3.5 mm stereo jack |
|---|
| Bluetooth | Bluetooth v4.2 (Bluetooth Low Energy (BLE)), 2402 to 2480 MHz |
|---|
| GPS | Via Leica FOTOS app |
|---|
